Foundation Isolation

Brand: Dynamech Systems Pvt Ltd
1,23,000 / 25 pieces

Product Specification:

Material Carbon Steel
Usage/Application Industrial
Brand Dynemech

Product Description:

Owing to our expertise, we are introducing a broad array of Foundation Isolation - Zeiss CMM. The...
View Complete Details
  • Product Details
  • Company Details

Product Specification:

Material Carbon Steel
Usage/Application Industrial
Brand Dynemech
Mounting Type Horizontal
Weight 1550 Kg
Type Foundation Isolation
Size of Concrete Block 1900 mmx2200 mmx1000 mm
Foundation Pit Size 2100 mmx2400mmx1100 mm
Measuring Range 700/1000/600 mm
Insulation Sheet 75 mm thick
Country of Origin Made in India

Product Description:

Owing to our expertise, we are introducing a broad array of Foundation Isolation - Zeiss CMM. The offered product range is designed with the aid of latest techniques by our professionals in compliance with the market standards. Extensively admired among customers all across the globe, this product range is provided in numerous specifications to choose from. Our honored customers can take this product range in different sizes at reasonable pricese Features:Sturdy construction Excellent efficiency Less maintenance Guide Lines:Pit should be 100% water proof; check ground water conditions.The inner surface of the pit should be clean, dry & smooth.As per the detailed layout supplied by Dynemech, place vibration damping plate set Dp Paste them to the pit base using – Pidlite SR-505 adhesive.Place filler foam in the gaps between the Insulation plate set Dp. Paste them to the pit surface.Place PVC on the entire pit surface and side walls. Seal the overlapping joints of the PVC sheet with adhesive tape so that the concrete water should not leak in to the pit base.Place 25mm thick wooden board layer and joint should be sealed with adhesive tape. This will act as a support for the initial concrete pour.Place another layer of PVC sheet on the pit base and the side walls joints sealed with adhesive tape.Pour concrete up to a depth of 150mmand allow it to dry, this will act as a compression plate. After drying the compression plate erect reinforcement and pour concrete in the rest of the concrete block volume. Concrete should be poured in layers of 300mm+300mm+350mm to complete a depth of 1100mm, allow each layer to dry and pour another layer.The concrete block and the pit tub should not come in contact with each other.Care should be taken that the concrete or concrete laced water should not leak in to the insulation plate area.The side gaps may be filled with rubberised cork scrap.Additional Information:Item Code: Zeiss-CMM
